RXM2LB2P7
Product ID:33677
Updated: 2026/4/3
Key Features
- 1Deliver high-performance 2000W output for demanding applications. 2、Integrate easily with a compact and space-saving design. 3、Ensure reliable operation with low noise and high efficiency. 4、Suit both industrial and commercial environments seamlessly. 5、Meet or exceed all international safety and compliance standards.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony Electromechanical Relays | Coil interference suppression | Without |
| Series name | Miniature | Product or Component Type | Plug-in relay |
| Device short name | RXM | Contacts type and composition | 2 C/O |
| [Ithe] conventional enclosed thermal current | 5 A -40…131 °F (-40…55 °C) | Contact operation | Standard |
| [Uc] control circuit voltage | 230 V AC 50/60 Hz | Status LED | With |
| Control Type | Without push-button | [Uimp] rated impulse withstand voltage | 4 kV 1.2/50 µs IEC 61810-7 |
| [Ie] rated operational current | 5 A AC-1/DC-1) NO IEC<br />2.5 A AC-1/DC-1) NC IEC<br />1 A 28 V DC-13) NO | Minimum switching capacity | 25 mW subject to switching frequency, environment or expected reliability level etc |
| Average coil consumption in VA | 1.2 AC | Operating time | 20 ms between coil de-energisation and making of the Off-delay contact<br />20 ms between coil energisation and making of the On-delay contact |
| CAD overall width | 0.8 in (21 mm) | CAD overall height | 1.06 in (27 mm) |
| CAD overall depth | 1.8 in (46 mm) | Minimum switching current | 5 mA subject to switching frequency, environment or expected reliability level etc |
| Minimum switching voltage | 5 V subject to switching frequency, environment or expected reliability level etc | Rated operational voltage limits | 184...253 V AC |
| [Ui] rated insulation voltage | 250 V IEC | Maximum switching voltage | 250 V AC<br />28 V DC |
| Drop-out voltage threshold | >= 0.15 Uc AC | Load current | 5 A 250 V AC<br />5 A 28 V DC |
| Maximum switching capacity | 1250 VA AC<br />140 W DC | Average resistance | 16500 Ohm at 73 °F (23 °C) +/- 15 % |
| Mechanical durability | 10000000 cycles | Electrical durability | 100000 cycles for resistive load<br />50000 cycles, 1 A at 28 V, DC-13 NO |
| Safety reliability data | B10d = 100000 | Operating rate | <= 1200 cycles/hour under load<br /><= 18000 cycles/hour no-load |
| Utilisation coefficient | 20 % | Dielectric strength | 2000 V AC between coil and contact with basic insulation<br />2000 V AC between poles with basic insulation<br />1000 V AC between contacts with micro disconnection |
| Protection category | RT I | Pollution degree | 3 |
| Operating position | Any position | Test levels | Level A group mounting |
| Sale per indivisible quantity | 10 | Contacts material | Silver alloy (Ag/Ni) |
| Net Weight | 0.068 lb(US) (0.031 kg) | IP degree of protection | IP40 conforming to IEC 60529 |
| Standards | CE<br />IEC 61810-1 (iss. 2) | Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
| Vibration resistance | 3 gn +/- 1 mm 10…50 Hz)operating IEC 60068-2-6<br />6 gn +/- 1 mm 10…50 Hz)not operating IEC 60068-2-6 | Shock resistance | 30 gnnot operating IEC 60068-2-27<br />10 gnin operation IEC 60068-2-27 |
