RXM4AB2B7TQ
Product ID:33639
Updated: 2026/4/3
Key Features
- 1Ensure high reliability and durability in demanding industrial environments. 2、Maximize space with a compact design and high power density. 3、Utilize a wide 36-264 VAC input voltage range for versatile compatibility. 4、Extend product lifespan with advanced thermal management to reduce maintenance. 5、Meet international safety standards like UL and CE for trusted performance.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony Relay | Series name | Miniature |
| Product or Component Type | Plug-in relay | Device short name | RXM |
| Contacts type and composition | 4 C/O | [Uc] control circuit voltage | 24 V AC 50/60 Hz |
| Status LED | With | Control Type | Lockable test button |
| Utilisation coefficient | 20 % | Shape of pin | Flat |
| [Ui] rated insulation voltage | 250 V IEC<br />300 V CSA<br />300 V UL | [Uimp] rated impulse withstand voltage | 2.5 kV 1.2/50 µs |
| Contacts material | AgNi | [Ie] rated operational current | 3 A 28 V DC) NC IEC<br />3 A 250 V AC) NC IEC<br />6 A 28 V DC) NO IEC<br />6 A 250 V AC) NO IEC<br />6 A 277 V AC) UL<br />8 A 30 V DC) UL |
| Continuous output current | 5 A | Maximum switching voltage | 250 V IEC |
| resistive rated load | 6 A 250 V AC<br />6 A 28 V DC | Maximum switching capacity | 1500 VA/168 W |
| Minimum switching capacity | 170 mW 10 mA, 17 V | Operating rate | <= 1200 cycles/hour under load<br /><= 18000 cycles/hour no-load |
| Mechanical durability | 10000000 cycles | Electrical durability | 100000 cycles resistive |
| average coil consumption in VA | 1.2 60 Hz | Average consumption | 1.2 VA 60 Hz |
| Drop-out voltage threshold | >= 0.15 Uc | operate time | 20 ms |
| release time | 20 ms | average coil resistance | 180 Ohm 20 °C +/- 15 % |
| Rated operational voltage limits | 19.2...26.4 V AC | Safety reliability data | B10d = 100000 |
| Protection category | RT I | Operating position | Any position |
| CAD overall height | 3.1 in (79 mm) | CAD overall depth | 3.09 in (78.45 mm) |
| Net Weight | 0.082 lb(US) (0.037 kg) | Device presentation | Complete product |
| Dielectric strength | 1300 V AC between contacts with micro disconnection<br />2000 V AC between coil and contact with basic insulation<br />2000 V AC between poles with basic insulation | Product Certifications | CE<br />GOST<br />Lloyd's<br />CSA<br />UL |
| Standards | EN/IEC 61810-1<br />UL 508<br />CSA C22.2 No 14 | Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
| Ambient air temperature for operation | -40…131 °F (-40…55 °C) | Vibration resistance | 3 gn +/- 1 mm 10…150 Hz)5 cycles in operation<br />5 gn +/- 1 mm 10…150 Hz)5 cycles not operating |
| IP degree of protection | IP40 conforming to EN/IEC 60529 | Shock resistance | 10 gnin operation<br />30 gnnot operating |
| Pollution degree | 2 |
Specifications may be subject to change without notice
