RXM4AB3P7TQ
Product ID:33743
Updated: 2026/7/14
Key Features
- 1Deliver high-performance 3000W output for demanding applications.
- 2Integrate easily with a compact, space-saving design.
- 3Ensure reliable, low-noise, and highly efficient operation.
- 4Meet international safety standards including UL and CE.
- 5Deploy in industrial, commercial, and data center environments.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony Relay | Series name | Miniature |
| Product or Component Type | Plug-in relay | Device short name | RXM |
| Contacts type and composition | 4 C/O | [Uc] control circuit voltage | 230 V AC 50/60 Hz |
| Status LED | With | Control Type | Without lockable test button |
| Utilisation coefficient | 20 % | Shape of pin | Flat |
| [Ui] rated insulation voltage | 250 V IEC<br />300 V CSA<br />300 V UL | [Uimp] rated impulse withstand voltage | 2.5 kV 1.2/50 µs |
| Contacts material | AgNi | [Ie] rated operational current | 3 A 28 V DC) NC IEC<br />3 A 250 V AC) NC IEC<br />6 A 28 V DC) NO IEC<br />6 A 250 V AC) NO IEC<br />6 A 277 V AC) UL<br />8 A 30 V DC) UL |
| Continuous output current | 5 A | Maximum switching voltage | 250 V IEC |
| resistive rated load | 6 A 250 V AC<br />6 A 28 V DC | Maximum switching capacity | 1500 VA/168 W |
| Minimum switching capacity | 170 mW 10 mA, 17 V | Operating rate | <= 1200 cycles/hour under load<br /><= 18000 cycles/hour no-load |
| Mechanical durability | 10000000 cycles | Electrical durability | 100000 cycles resistive |
| average coil consumption in VA | 1.2 60 Hz | Average consumption | 1.2 VA 60 Hz |
| Drop-out voltage threshold | >= 0.15 Uc | operate time | 20 ms |
| release time | 20 ms | average coil resistance | 15000 Ohm 20 °C +/- 15 % |
| Rated operational voltage limits | 184...253 V AC | Safety reliability data | B10d = 100000 |
| Protection category | RT I | Operating position | Any position |
| Net Weight | 0.082 lb(US) (0.037 kg) | Device presentation | Complete product |
| Dielectric strength | 1300 V AC between contacts with micro disconnection<br />2000 V AC between coil and contact with basic insulation<br />2000 V AC between poles with basic insulation | Product Certifications | GOST<br />UL<br />Lloyd's<br />CE<br />CSA |
| Standards | UL 508<br />EN/IEC 61810-1<br />CSA C22.2 No 14 | Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) |
| Ambient air temperature for operation | -40…131 °F (-40…55 °C) | Vibration resistance | 3 gn +/- 1 mm 10…150 Hz)5 cycles in operation<br />5 gn +/- 1 mm 10…150 Hz)5 cycles not operating |
| IP degree of protection | IP40 conforming to EN/IEC 60529 | Shock resistance | 10 gnin operation<br />30 gnnot operating |
| Pollution degree | 2 |
