RXM4SOC24D
Product ID:33772
Updated: 2026/4/3
Key Features
- 1Achieve high power density for space-saving installations. 2、Utilize advanced protection features for reliable, safe operation. 3、Benefit from a wide input voltage range for versatile global use. 4、Reduce energy consumption with high 95% efficiency ratings. 5、Ensure optimal performance with built-in thermal management.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony Relay | Series name | Miniature |
| Product or Component Type | Plug-in relay | Device short name | RXM |
| Contacts type and composition | 4 C/O | [Uc] control circuit voltage | 24 V DC |
| [Ithe] conventional enclosed thermal current | 6 A -40…131 °F (-40…55 °C) | Status LED | With |
| Control Type | Lockable test button | Utilisation coefficient | 20 % |
| Shape of pin | Flat | [Ui] rated insulation voltage | 250 V IEC<br />300 V CSA<br />300 V UL |
| [Uimp] rated impulse withstand voltage | 2.5 kV 1.2/50 µs | Contacts material | AgNi |
| [Ie] rated operational current | 3 A 28 V DC) NC IEC<br />3 A 250 V AC) NC IEC<br />6 A 28 V DC) NO IEC<br />6 A 250 V AC) NO IEC<br />6 A 277 V AC) UL<br />8 A 30 V DC) UL | Maximum switching voltage | 250 V IEC |
| resistive rated load | 6 A 250 V AC<br />6 A 28 V DC | Maximum switching capacity | 1500 VA/168 W |
| Minimum switching capacity | 170 mW 10 mA, 17 V | Operating rate | <= 1200 cycles/hour under load<br /><= 18000 cycles/hour no-load |
| Mechanical durability | 10000000 cycles | Electrical durability | 100000 cycles resistive |
| average coil consumption | 0.9 W | Drop-out voltage threshold | >= 0.1 Uc |
| operate time | 20 ms | release time | 20 ms |
| average coil resistance | 650 Ohm 20 °C +/- 10 % | Rated operational voltage limits | 19.2...26.4 V DC |
| Safety reliability data | B10d = 100000 | Protection category | RT I |
| Operating position | Any position | Net Weight | 0.082 lb(US) (0.037 kg) |
| Device presentation | Complete product | Dielectric strength | 1300 V AC between contacts with micro disconnection<br />2000 V AC between coil and contact<br />2000 V AC between poles |
| Product Certifications | UL<br />CSA<br />GOST<br />CE<br />Lloyd's | Standards | EN/IEC 61810-1<br />CSA C22.2 No 14<br />UL 508 |
| Ambient Air Temperature for Storage | -40…185 °F (-40…85 °C) | Ambient air temperature for operation | -40…131 °F (-40…55 °C) |
| Vibration resistance | 3 gn +/- 1 mm 10…150 Hz)5 cycles in operation<br />5 gn +/- 1 mm 10…150 Hz)5 cycles not operating | IP degree of protection | IP40 conforming to EN/IEC 60529 |
| Shock resistance | 10 gnin operation<br />30 gnnot operating | Pollution degree | 2 |
Specifications may be subject to change without notice
