RXZE1M4C
Product ID:33780
Updated: 2026/4/3
Key Features
- 1Deliver high-performance 1000W output for demanding applications. 2、Integrate easily with a compact design into various systems. 3、Ensure global compatibility with a wide 85-264V input range. 4、Achieve up to 92% efficiency to reduce energy consumption. 5、Protect your system with built-in safety and reliability features.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony Electromechanical Relays | Product compatibility | Plug-in relay RXM 2 C/O<br />Plug-in relay RXM 4 C/O |
| Device short name | RXZ | [Ith] conventional free air thermal current | 7 A |
| Product or Component Type | Socket | Contacts type and composition | 4 C/O |
| [Ue] rated operational voltage | 250 V AC IEC | Connections - terminals | Screw clamp terminals, 1 x 0.2...1 x 1.0 mm² AWG 24...AWG 17) flexible with cable end<br />Screw clamp terminals, 2 x 0.2...2 x 1.0 mm² AWG 24...AWG 17) flexible with cable end<br />Screw clamp terminals, 1 x 0.5...1 x 1.5 mm² AWG 20...AWG 16) solid without cable end<br />Screw clamp terminals, 2 x 0.5...2 x 1.5 mm² AWG 20...AWG 16) solid without cable end |
| Tightening torque | < 0.8 N.m M3 | Fixing mode | By screw (panel)<br />Clip-on (35 mm symmetrical DIN rail) |
| Contact terminal arrangement | Mixed | [Uimp] rated impulse withstand voltage | 4 kV |
| Overvoltage category | III | Pollution degree | 3 |
| Sale per indivisible quantity | 10 | Width | 1.1 in (29 mm) |
| Net Weight | 0.117 lb(US) (0.053 kg) | Dielectric strength | 2500 V |
| Standards | IEC 61984 | marking | CE |
| Ambient Air Temperature for Storage | -67…185 °F (-55…85 °C) | Ambient Air Temperature for Operation | -40…131 °F (-40…55 °C) |
Specifications may be subject to change without notice
