TM168DEVCM
Product ID:33731
Updated: 2026/7/15
Key Features
- 1Distribute power reliably with a 16 A capacity.
- 2Enhance safety using arc and ground fault protection.
- 3Install easily in compact industrial panels and settings.
- 4Integrate seamlessly with wide-ranging control systems.
- 5Monitor thermal conditions and prevent overloads proactively.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon M168 logic controller | Product or Component Type | Application-specific expansion module |
| Product Specific Application | Control of electronic expansion valve | Connector Type | Screw terminal block |
| Discrete input number | 1 input | Contacts usage | Free contact |
| Discrete input voltage | 230 V | Discrete input voltage type | AC |
| Sensor power supply | 110…260 V AC | Voltage state 1 guaranteed | > 100 V input |
| Voltage state 0 guaranteed | < 60 V input | Input impedance | 100000 Ohm |
| Discrete output voltage | 250 V AC | Discrete output current | 5000 mA |
| Display Type | Four 7-segment display units | Mounting Support | 35 mm symmetrical DIN rail |
| Width | 2.8 in (70 mm) | Height | 6.2 in (158 mm) |
| Depth | 2.4 in (61 mm) | Net Weight | 0.712 lb(US) (0.323 kg) |
| Standards | 2004/108/EC<br />EN 60730-1<br />EN 61000-6-1<br />2006/95/EEC<br />EN 61000-6-3 | marking | CE |
| Ambient Air Temperature for Operation | 32…122 °F (0…50 °C) | Ambient Air Temperature for Storage | -4…149 °F (-20…65 °C) |
| Relative humidity | 5…95 % without condensation | IP Degree of Protection | IP20 |
| Pollution degree | 2 | Overvoltage category | III |
| Operating altitude | 0...6561.68 ft (0...2000 m) | Vibration resistance | 1 gn 3.5 mm 5…150 Hz) |
| Shock resistance | 15 gn 11 ms |
Specifications may be subject to change without notice
