TM168GDTS
Product ID:33734
Updated: 2026/4/4
Key Features
- 1Enhance safety with advanced arc fault detection. 2、Handle up to 160A current for heavy-duty applications. 3、Save space using a compact design with IP20 protection. 4、Optimize performance via integrated thermal monitoring. 5、Ensure global compliance with international safety standards.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon M168 logic controller | Product or Component Type | Graphic display |
| Power Consumption in W | 5 W | Display Type | LCD touch screen |
| Display colour | Monochrome | Display Resolution | 240 x 140 pixels |
| Number of key | 6 | Supply | External source |
| Standards | EN/IEC 60529<br />CSA 60730-1<br />UL 60730-1<br />EN 60730-1 | marking | CE |
| Realtime clock | With <= 30 s/month 2 days | Local signalling | for power supply 1 LED (green)<br /> for bus activity RX (reception) 1 LED (red)<br /> for bus activity TX (transmission) 1 LED (red) |
| Memory type | Internal | Backup Time | 10 years |
| Number of read/write cycles | 1000000 | Supply voltage limits | 18…30 V |
| Immunity to microbreaks | 10 ms | Height | 5.2 in (133 mm) |
| Width | 4.8 in (122 mm) | Depth | 1.4 in (36 mm) |
| Net Weight | 0.591 lb(US) (0.268 kg) | Ambient Air Temperature for Operation | 32…131 °F (0…55 °C) |
| Ambient Air Temperature for Storage | -4…158 °F (-20…70 °C) | IP degree of protection | IP40 front face: |
| Pollution degree | 2 | Overvoltage category | III |
| Vibration resistance | 3.5 mm 5…8.4 Hz)EN/IEC 60028-2-6<br />1 gn 8.4…150 Hz)EN/IEC 60028-2-6 | Shock resistance | 15 gn 11 ms |
Specifications may be subject to change without notice
