TM171EP14R
Product ID:33852
Updated: 2026/7/15
Key Features
- 1Deliver high-performance power with a 14A current rating.
- 2Integrate easily using a compact, space-saving design.
- 3Ensure long-term reliability with robust industrial construction.
- 4Automate diverse applications from control to safety systems.
- 5Operate securely meeting international safety standards.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon M171/M172 | Product or Component Type | Additional I/O module |
| Product Specific Application | HVAC and pumping solution | Total inputs/outputs | 14 |
| Discrete input number | 4 | Discrete output number | 1 relay outputs SPDT with independent common<br />3 relay outputs SPST with same common |
| Discrete output current | 3 A relay | Analogue input number | 4 configurable by pair |
| Analogue output number | 2 voltage 0...10 V | Number of port | 1 CAN port - screw terminal block |
| Input/output number | 2 analog output<br />4 digital output<br />4 analog input<br />4 digital input | Discrete input logic | Sink or source (positive/negative) |
| Discrete input voltage | 24 V AC/DC | Discrete input current | 2.5 mA |
| input impedance | 20 kOhm | Analogue input type | voltage 0...5 V ratiometric)<br /> current 4...20 mA<br /> voltage 0...10 V<br />NTC temperature probe - 50...110 °C 0.1 °C<br />NTC temperature probe - 40...137 °C 0.1 °C extended)<br />PTC temperature probe - 50...150 °C 0.1 °C |
| Sensor power supply | 12 V DC 85 mA | [Us] rated supply voltage | 24 V |
Specifications may be subject to change without notice
