TM171PFE03HR
Product ID:33588
Updated: 2026/4/4
Key Features
- 1Ensure high reliability and durability for long-lasting performance. 2、Install easily in tight spaces with a compact design. 3、Protect systems with advanced arc and ground fault detection. 4、Handle heavy-duty applications with up to 100A current capacity. 5、Meet global compliance with international safety standards.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon M171/M172 | Product or Component Type | Programmable controllers |
| Product Specific Application | HVAC and pumping solution | Variant | Programmable |
| Total inputs/outputs | 3 | Analogue input number | 1 analog input NTC board)<br />1 analog input NTC<br />1 relative humidity sensor board) |
| Number of port | 1 CAN port - screw terminal block<br />1 Ethernet - RJ45 Modbus TCP and BACnet IP with webserver)<br />1 RS485 - screw terminal block Modbus serial link or BACnet MS/TP)<br />1 | Input/output number | 3 analog input |
| Analogue input type | NTC temperature probe - 50...110 °C 0.1 °C extended)<br />NTC temperature probe - 40...150 °C 0.1 °C<br /> humidity probe 0...100 % RH 0.01 % RH | [Us] rated supply voltage | 24 V ±10% AC<br />48 V DC |
| Power consumption in W | 24 VA 24 V AC<br />15 W 20...38 V DC | Realtime clock | Without clock at -4…149 °F (-20…65 °C) |
| Display type | Without Display | Overvoltage category | II |
| Local signalling | without | Mounting Support | Panel mounting with accessory<br />DIN rail |
| Width | 2.8 in (72 mm) | Height | 4.3 in (110 mm) |
| Depth | 2.4 in (60.5 mm) | Net Weight | 0.49 lb(US) (0.22 kg) |
| Standards | EN/IEC 60730 | Product Certifications | CE<br />EAC<br />CSA<br />cURus<br />RCM |
| Ambient air temperature for operation | -4…149 °F (-20…65 °C) UL 60730-1 | Ambient Air Temperature for Storage | -4…185 °F (-20…85 °C) |
| Relative humidity | 10…90 % non-condensing | IP degree of protection | IP20 |
| Pollution degree | 2 |
Specifications may be subject to change without notice
