TM173ODM22S
Product ID:33800
Updated: 2026/4/4
Key Features
- 1Deliver 1730W of high-performance power reliably. 2、Integrate easily with a compact and space-saving design. 3、Operate with low noise and high efficiency for reliability. 4、Meet international safety standards including UL and CE. 5、Apply ideally to industrial, medical, and data center needs.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon M171/M172/M173 | Product or Component Type | Programmable controllers |
| Product Specific Application | HVAC and pumping solution | Variant | Programmable |
| Total inputs/outputs | 22 | Discrete input number | 6 |
| Discrete output number | 3 relay outputs SPST with same common<br />2 solid state, isolated SPST with independent common | Discrete output current | 5 A relay SPST<br />0.5 A solid state, isolated |
| Analogue input number | 6 configurable by pair<br />1 configurable | Analogue output number | 1 voltage/current 0…10 V or 4…20 mA<br />3 voltage 0...10 V or PWM (10Hz...2 kHz) |
| Number of port | 1 CAN port - screw terminal block<br />1 USB type C<br />2 RS485 - screw terminal block Modbus serial link)<br />1 display port - TTL connector<br />1 communication module port | Input/output number | 6 digital input<br />5 digital output<br />7 analog input<br />4 analog output |
| Discrete input logic | Sink or source (positive/negative) | Contacts usage | Volt-free contacts |
| Discrete input voltage | 24 V AC/DC | Discrete input current | 2.5 mA |
| input impedance | 20 kOhm | Analogue input type | NTC 103AT-2 Beta 3435 temperature probe - 50...100 °C 0.1 °C 10 kOhm<br />Pt 1000 temperature probe - 50...400 °C 0.1 °C 2 kOhm<br /> voltage 0...10 V 0.001 V > 10 kOhm<br /> voltage 0...5 V 0.001 V 110 kOhm<br /> current 4...20 mA 13 bits 100 Ohm<br /> direct input > 10 kOhm |
| Measurement accuracy | NTC NK103 Beta 3977 - 40...+110 °C +/- 1 °C<br /> NTC NK103 Beta 3977 110...137 °C +/- 1.9 °C<br /> NTC 103AT-2 Beta 3435 - 50…110 °C +/- 1 °C<br /> PTC - 55...155 °C +/- 1.1 °C<br /> Pt 1000 - 100...-50 °C +/- 5 °C<br /> Pt 1000 - 50...100 °C +/- 1 °C<br /> Pt 1000 100…400 °C +/- 5 °C<br />0...20 mA 0...4 mA +/- 2 % of full scale +/- 1 digit<br />0...20 mA 4...20 mA +/- 1 % of full scale +/- 1 digit<br />4...20 mA +/- 1 % of full scale +/- 1 digit<br />0...10 V +/- 1 % of full scale +/- 1 digit<br />0...5 V +/- 1 % of full scale +/- 1 digit<br />HOhm 0...1500 hOhm +/- 8.5 hOhm<br />DaOhm 0...300 daOhm +/- 2.5 daOhm | Sensor power supply | 5 V DC 50 mA supplied by the controller<br />24 V DC 125 mA supplied by the controller |
| [Us] rated supply voltage | 24 V +/- 10 % AC<br />20...38 V DC | Power consumption in W | 10 W 24 V AC/DC |
| Realtime clock | Built-in clock, clock drift <= 30 s/month at -4…149 °F (-20…65 °C) | Display type | LED |
| Memory Type | 1 MB flash<br />380 kB RAM | Overvoltage category | II |
| Local signalling | for USB pendrive download status 1 LED (green) | Mounting Support | Panel mounting with accessory<br />DIN rail |
| Width | 2.8 in (72 mm) | Height | 4.3 in (110 mm) |
| Depth | 2.4 in (60 mm) | Net Weight | 0.392 lb(US) (0.178 kg) |
| Directives | 2014/30/EU - electromagnetic compatibility<br />2014/35/EU - low voltage directive | Standards | CAN/CSA-E60730-1<br />CSA E60730-2-9<br />EN 60068-2-27<br />EN 60068-2-6 Fc<br />EN 60730-1<br />EN 60730-2-9<br />UL 60730-1<br />UL 60730-2-9<br />IEC 61000-4-2<br />IEC 61000-4-3<br />IEC 61000-4-4<br />IEC 61000-4-5<br />IEC 61000-4-6<br />IEC 61000-4-11<br />UL94 (material V0) |
| Product Certifications | EAC (pending)<br />CE<br />cURus<br />CSA<br />RCM (pending) | Ambient air temperature for operation | -4…149 °F (-20…65 °C) UL 60730-1<br /> EN 60730-1<br /> EN 60730-2-9 |
| Ambient Air Temperature for Storage | -22…158 °F (-30…70 °C) | Relative humidity | 5…95 % non-condensing |
| IP degree of protection | IP20 conforming to EN/IEC 60730 | Pollution degree | 2 |
| Operating altitude | 0...6561.68 ft (0...2000 m) |
Specifications may be subject to change without notice
