TSXAEY420
Product ID:34403
Updated: 2026/4/4
Key Features
- 1Acquire data rapidly via 4 high-level fast inputs. 2、Ensure precision with 16-bit analog-to-digital conversion. 3、Operate efficiently with 500mA at 5VDC consumption. 4、Gain reliability with a comprehensive 2-year warranty. 5、Support multiple voltage and current ranges for compatibility.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon Premium Automation platform | Product or Component Type | Analog input module |
| Input level | High level | Analogue input number | 4 |
| Analogue input type | Current 0...20 mA<br />Current 4...20 mA<br />Voltage +/- 10 V<br />Voltage 0...10 V<br />Voltage 0...5 V<br />Voltage 1...5 V | Analog/digital conversion | 16 bits |
| Nominal read cycle time | 1 ms | Measurement error | 0.1 % of full scale +/- 10 V 25 °C<br />0.1 % of full scale 0...10 V 25 °C<br />0.2 % of full scale +/- 10 V 0...60 °C<br />0.2 % of full scale 0...10 V 0...60 °C<br />0.2 % of full scale 0...20 mA 25 °C<br />0.2 % of full scale 0...5 V 25 °C<br />0.2 % of full scale 1...5 V 25 °C<br />0.2 % of full scale 4...20 mA 25 °C<br />0.4 % of full scale 0...20 mA 0...60 °C<br />0.4 % of full scale 0...5 V 0...60 °C<br />0.4 % of full scale 1...5 V 0...60 °C<br />0.4 % of full scale 4...20 mA 0...60 °C |
| Isolation between channels and bus | 1000 Vrms | Isolation between channels and ground | 1000 Vrms |
| Isolation between channels | Common point | Common mode between channels | None |
| Input overvoltage protection | -15…15 V at state 0 250 Ohm<br />-30…30 V at state 1 250 Ohm | Electrical connection | 1 connector SUB-D 25 |
| Overcurrent | -30…30 mA at state 1 250 kOhm | marking | CE |
| Current consumption | 500 mA 5 V DC | Module format | Standard |
| Net Weight | 0.73 lb(US) (0.33 kg) | Standards | IEC 1131 |
| Product Certifications | BV<br />LR<br />ABS<br />RINA<br />RMRS<br />GL<br />DNV | Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) |
| Ambient Air Temperature for Storage | -13…158 °F (-25…70 °C) | Relative Humidity | 10…95 % without condensation for operation<br />5…95 % without condensation for storage |
| Operating altitude | 0...6561.68 ft (0...2000 m) | Protective treatment | TC |
| IP Degree of Protection | IP20 | Pollution degree | 2 |
