TSXDMZ64DTK
Product ID:34521
Updated: 2026/7/15
Key Features
- 1Distribute power through 64 high-capacity outlets.
- 2Install easily with a compact design for tight spaces.
- 3Optimize performance with advanced thermal management.
- 4Ensure safety by meeting IEC and UL standards.
- 5Deploy in data centers, industrial, and commercial applications.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon TSX Micro automation platform | Product or Component Type | Discrete solid state I/O base DC |
| Discrete input number | 32 1 HE-10 connector | Discrete input voltage | 24 V DC positive |
| Discrete input current | 3.5 mA | Discrete input type | Current sink |
| Discrete output number | 32 1 HE-10 connector | Discrete output voltage | 24 V DC |
| Discrete output current | 0.1 mA | Discrete output logic | Positive |
| Input voltage limits | >= 11 V at state 1<br />< 5 V at state 0 | Current state 0 guaranteed | <= 1.5 mA |
| Current state 1 guaranteed | >= 2.5 mA | input impedance | 6.3 Ohm |
| Response time | 0.1...7.5 ms from state 1 to state 0 input<br />0.1...7.5 ms from state 0 to state 1 input<br />< 2.5 ms from state 1 to state 0 output<br />< 2.5 ms from state 0 to state 1 output | Input compatibility | 2-wire/3-wire proximity sensor |
| Current consumption | 197 mA | Power dissipation in W | 3.5 W by module output<br />0.15 W by channel output<br />5 W input |
| Output voltage limits | 19...30 V | Output current limits | 0.25 A |
| Maximum leakage current | 0.1 mA at state 0 | [Ures] residual voltage | 1.5 V |
| Load impedance ohmic | 220 Ohm | Switching frequency | < 0.5/LI² Hz |
| Output overvoltage protection | By zener diode | Output short-circuit protection | By current limiter and electronic circuit breaker |
| Reverse polarity protection | Reverse diode on power supply | Paralleling of outputs | Yes : 3 maximum |
| Isolation voltage | 1500 V 1 s | Net Weight | 0.90 lb(US) (0.41 kg) |
| Standards | IEC 1131-2 Type 1 |
Specifications may be subject to change without notice
