TSXDSZ08T2
Product ID:34550
Updated: 2026/4/3
Key Features
- 1Deliver high-performance 8kW output for demanding industrial loads. 2、Install the compact module in space-constrained control panels. 3、Extend operational lifespan with advanced thermal management systems. 4、Ensure compliance with international safety standards including UL and CE. 5、Optimize reliability for critical commercial and industrial applications.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon TSX Micro automation platform | Product or Component Type | Discrete output module |
| Discrete output number | 8 screw terminal block | Discrete output voltage | 24 V DC |
| Discrete output current | 0.5 mA | Discrete output logic | Positive |
| Output voltage limits | 19...30 V | Output current limits | 0.625 A |
| Maximum leakage current | 0.5 mA at state 0 | [Ures] residual voltage | 0.3 V |
| Load impedance ohmic | 48 Ohm | Response Time | < 0.5 ms at state 1<br />< 0.5 ms at state 0 |
| Switching frequency | < 0.6/LI² Hz | Output overvoltage protection | By zener diode |
| Output short-circuit protection | Thermal circuit breaker<br />Current limiter | Reverse polarity protection | Reverse diode on power supply |
| Paralleling of outputs | Yes : 2 maximum | current consumption | 38 mA |
| Power dissipation in W | 3.5 W by module<br />0.15 W by channel | Isolation voltage | 1500 V 1 s |
| Net Weight | 0.53 lb(US) (0.24 kg) |
Specifications may be subject to change without notice
