TSXSAY1000
Product ID:34753
Updated: 2026/4/3
Key Features
- 1Safeguard equipment from power surges and outages. 2、Offer up to 1000VA for extended operation. 3、Reduce energy costs with high efficiency. 4、Save space with a compact, sleek design. 5、Ensure maximum uptime with quality components.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon Premium Automation platform | Product or Component Type | AS-Interface master module |
| Range Compatibility | AS-Interface cabling system | Actuator sensor interface profile [AS-i] | M2E |
| AS-i version | V2 | Addressing | Standard and extended |
| Number of server device(s) | 31, extended<br />31, standard | Type of connectable interfaces | Analog I/Os, standard<br />Discrete I/Os (4I/3O), extended<br />Discrete I/Os (4I/4O), standard<br />Safety interfaces, standard |
| Electrical connection | 1 male connector SUB-D, 3 ways | Supply | Via power supply integrated into the host platform of the module |
| Current consumption | 450 mA 5 V DC | Local signalling | Display unit |
| Number of modules per base controller | 1 TSX570.<br />1 TSX57C.<br />2 TSX571.<br />4 TSX572.<br />8 TSX573.<br />8 TSX574.<br />8 TSX575.<br />8 TSX576. | Net Weight | 0.75 lb(US) (0.34 kg) |
| Standards | IEC 60068-2-27, Ea tests<br />IEC 60068-2-6, Fc tests | Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) |
| Ambient Air Temperature for Storage | -13…158 °F (-25…70 °C) | IP Degree of Protection | IP20 |
Specifications may be subject to change without notice
