TSXWMY100C
Product ID:34792
Updated: 2026/7/14
Key Features
- 1Deliver high-performance 100A output for demanding applications.
- 2Save space with a compact and efficient design.
- 3Operate flexibly across a wide input voltage range.
- 4Ensure high efficiency and quiet, low-noise operation.
- 5Meet international safety and compliance standards.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Modicon Premium Automation platform | Product or Component Type | Ethernet TCP/IP module |
| Physical interface | RJ45 - 10BASE-T/100BASE-TX 1 twisted pair | Transmission rate | 10/100 Mbit/s |
| Communication service | Modbus TCP messaging<br />SMTP e-mail notification<br />SNMP agent<br />SOAP XML Web (client/server)<br />Uni-TE messaging | Supply | Via the power supply of the rack |
| Local signalling | for collision detection (COL) 1 LED (red)<br /> for configuration status (STS) 1 LED (amber)<br /> for Ethernet network status (RUN) 1 LED (green)<br /> for Ethernet port fault (ERR) 1 LED (red)<br /> for transmission activity (TX) 1 LED (amber)<br /> for reception activity (RX) 1 LED (amber) | communication port protocol | Modbus TCP<br />Uni-Telway |
| Maximum number of connections | 64 | Web server | Transparent ready class D10 |
| web feature | Rack viewer<br />FactoryCast HMI active<br />Data Editor (via PC terminal)<br />FactoryCast configurable | Memory description | User web page size 8 MB |
| marking | CE | Product compatibility | PL7 Pro<br />Unity Pro |
| Current consumption | 360 mA 5 V DC | Module format | Standard |
| Net Weight | 0.75 lb(US) (0.34 kg) | Standards | FM Class 1 Division 2 group A<br />UL 508<br />FM Class 1 Division 2 group B<br />FM Class 1 Division 2 group D<br />FM Class 1 Division 2 group C<br />CSA 1010-1<br />EN 61131-2 |
| IP Degree of Protection | IP20 | Protective treatment | Conformal coating Humiseal 1A33 |
| Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) | Relative humidity | 10…95 % 140 °F (60 °C) without condensation |
Specifications may be subject to change without notice
