XB4BV65
Product ID:34945
Updated: 2026/4/8
Key Features
- 1Distribute power reliably with high current capacity. 2、Install easily in compact spaces for efficiency. 3、Enhance safety with integrated arc fault protection. 4、Integrate seamlessly with various electrical systems. 5、Ensure longevity through durable construction.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony XB4 | Product or Component Type | Pilot light |
| Device short name | XB4 | Bezel material | Chromium plated metal |
| Fixing collar material | Zamak | Head type | Standard |
| Mounting diameter | 0.9 in (22.5 mm) | Sale per indivisible quantity | 1 |
| Shape of signaling unit head | Round | cap/operator or lens colour | Orange |
| Operator additional information | With plain lens | Light source | Bulb not included |
| Bulb base | BA 9s | Light block supply | Direct <2.4 W |
| [Us] rated supply voltage | <= 250 V | Height | 1.9 in (47 mm) |
| Width | 1.2 in (30 mm) | Depth | 2.2 in (55 mm) |
| Terminals description ISO n°1 | (X1-X2)PL | Net Weight | 0.165 lb(US) (0.075 kg) |
| Resistance to high pressure washer | 1015.3 psi (7000000 Pa) 131 °F (55 °C) 0.1 m | Connections - terminals | Screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1<br />Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1 |
| [Ui] rated insulation voltage | 250 V 3)IEC 60947-1 | [Uimp] rated impulse withstand voltage | 4 kV IEC 60947-1 |
| Signalling type | Steady | Device presentation | Complete product |
| Protective treatment | TH | Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
| Ambient Air Temperature for Operation | -40…131 °F (-40…55 °C) | Electrical shock protection class | Class I IEC 60536 |
| IP degree of protection | IP66 IEC 60529<br />IP67<br />IP69<br />IP69K | NEMA degree of protection | NEMA 13<br />NEMA 4X |
| IK degree of protection | IK06 conforming to IEC 50102 | Standards | IEC 60947-5-4<br />IEC 60947-5-1<br />IEC 60947-5-5<br />UL 508<br />CSA C22.2 No 14<br />JIS C8201-5-1<br />IEC 60947-1<br />JIS C8201-1 |
| Product Certifications | UL Listed<br />CSA | Vibration resistance | 5 gn 12…500 Hz)IEC 60068-2-6 |
| Shock resistance | 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27<br />50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
Specifications may be subject to change without notice
