ZB6EH0B
Product ID:26922
Updated: 2026/7/23
Key Features
- 1Designed for Harmony XB6 series with body and fixing collar.
- 2Equip with Faston connectors for easy terminal connections.
- 3Ensure reliable operation with 250 V rated insulation voltage.
- 4Comply with EU and China RoHS directives, mercury-free.
- 5Withstand vibrations and shocks for long-lasting performance.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony XB6 | Product or Component Type | Complete body for pilot lights |
| Device short name | ZB6 | Sale per indivisible quantity | 5 |
| Connections - terminals | Faston connectors 2.8 x 0.5 mm | Light source | Incandescent (bulb not included) |
| Bulb base | BA 9s | Light block supply | Direct |
| [Us] Rated Supply Voltage | <= 24 V AC/DC | Terminals description ISO n°1 | (X1-X2)PL |
| Net Weight | 0.007 lb(US) (0.003 kg) | Operating position | Any position |
| [Ui] rated insulation voltage | 250 V 2)EN/IEC 60947-1 | [Uimp] rated impulse withstand voltage | 4 kV EN 60947-1 |
| Signalling type | Steady | Protective treatment | TC |
| Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) | Ambient Air Temperature for Operation | -13…158 °F (-25…70 °C) |
| Electrical shock protection class | Class II IEC 61140 | Standards | UL 508<br />EN/IEC 60947-5-5<br />EN/IEC 60947-1<br />JIS C 4520<br />CSA C22.2 No 14<br />JIS C 852<br />EN/IEC 60947-5-1 |
| Product Certifications | GOST<br />UL<br />CCC<br />CSA | Vibration resistance | +/- 3 mm 2…500 Hz)IEC 60068-2-6<br />5 gn 2…500 Hz)IEC 60068-2-6 |
| Shock resistance | 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27<br />50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
Specifications may be subject to change without notice
