ZBRM22
Product ID:27770
Updated: 2026/7/22
Key Features
- 1Construct durable polycarbonate for long-lasting performance.
- 2Achieve IP65 protection per IEC 60529 against dust and water.
- 3Operate easily with an ergonomic interface design.
- 4Deploy flexibly for both mobile and fixed applications.
- 5Select this Green Premium product for RoHS compliance.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony XB5R | Product or Component Type | Empty handy box |
| Device short name | ZBRM | Product destination | For XB5R Ø 22 mm control units |
| Control station application | Two functions | Colour of base of enclosure | Green Pantone 355C) |
| Colour of cover | Dark grey RAL 7016) | Material | Polycarbonate |
| Net Weight | 0.24 lb(US) (0.11 kg) | Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
| Ambient Air Temperature for Operation | -13…131 °F (-25…55 °C) | IP degree of protection | IP65 IEC 60529 |
| IK degree of protection | IK03 conforming to EN 50102 | Standards | ETSI EN 301 489-3<br />ETSI EN 301 489-1<br />ETSI EN 300 440-2<br />UL 508<br />CSA C22.2 No 14<br />ETSI EN 300 440-1<br />EN/IEC 60947-5-1 |
| Product Certifications | FCC<br />C-tick<br />CE<br />ANATEL<br />SRRC<br />BT 2006/95/EC<br />GOST<br />RSS | Directives | 1999/5/EC - R&TTE directive<br />2004/108/EC - electromagnetic compatibility |
Specifications may be subject to change without notice
