ZBV63
Product ID:27911
Updated: 2026/4/6
Key Features
- 1Integrate seamlessly with BA9s base bulbs. 2、Support both AC and DC voltage up to 250V. 3、Install quickly with fast-on terminals. 4、Ensure durability with a robust plastic body. 5、Explore recommended replacement options for continued support.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Range of Product | Harmony XB4<br />Harmony XB5 | Product or Component Type | Light block |
| Device short name | ZBV | Sale per indivisible quantity | 5 |
| Connections - terminals | Faston connector 1 x 6.35 mm<br />Faston connector 2 x 2.8 mm | Signalling type | Steady |
| Light source | Bulb not included | Bulb base | BA 9s |
| Light block supply | Direct | [Us] rated supply voltage | 250 V |
| Net Weight | 0.037 lb(US) (0.017 kg) | Service life | 100000 h at rated voltage and 25 °C |
| Surge withstand | 1 kV IEC 61000-4-5 | Mounting of block | Front mounting |
| Electrical composition code | M7<br />M8<br />MF2<br />P3<br />PF2 | Protective treatment | TH |
| Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) | Ambient Air Temperature for Operation | -40…158 °F (-40…70 °C) |
| IP degree of protection | IP20 IEC 60529 | Standards | CSA C22.2 No 14<br />IEC 60947-5-1<br />IEC 60947-5-4<br />IEC 60947-1<br />UL 508<br />JIS C8201-5-1<br />IEC 60947-5-5<br />JIS C8201-1 |
| Resistance to fast transients | 2 kV IEC 61000-4-4 | Resistance to electromagnetic fields | 9.1 V/m (10 V/m) IEC 61000-4-3 |
| Resistance to electrostatic discharge | 6 kV on contact (on metal parts) IEC 61000-4-2<br />8 kV in free air (in insulating parts) IEC 61000-4-2 | Electromagnetic emission | Class B IEC 55011 |
Specifications may be subject to change without notice
