IQ20-07BPSDU2S
Product ID:54829
Updated: 2026/7/7
Key Features
- 1Accurately detects metallic objects with advanced inductive technology.
- 2Designed for maximum availability and durability in harsh environments.
- 3Suitable for various detection, counting, and positioning tasks in factory automation.
- 4Wear-free and unaffected by external influences, ensuring consistent performance.
- 5Available in different configurations to meet specific industrial needs.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Housing | Rectangular | Dimensions (W x H x D) | 20 mm x 32 mm x 8 mm |
| Sensing range Sn | 7 mm | Safe sensing range Sa | 5.67 mm |
| Installation type | Flush | Switching frequency | 150 Hz |
| Connection type | Cable, 3-wire, 2 m | Switching output | PNP |
| Output function | NO | Electrical wiring | DC 3-wire |
| Enclosure rating | IP67 | Supply voltage | 10 V DC ... 30 V DC |
| Ripple | ≤ 10 % | Voltage drop | < 2.5 V |
| Time delay before availability | ≤ 20 ms | Hysteresis | 1 % ... 15 % |
| Reproducibility | ± 5 % | Temperature drift (of Sr) | ± 10 % |
| EMC | According to EN 60947-5-2 | Continuous current Ia | ≤ 200 mA |
| Cable material | PUR | Short-circuit protection | ✔ |
| Shock and vibration resistance | 30 g, 11 ms / 10 ... 55 Hz, 1 mm | Ambient operating temperature | –25 °C ... +70 °C |
| Housing material | Zinc diecast, GD Zn | Sensing face material | Plastic, PA12 |
| Note | The values are reference values which may vary | Stainless steel (V2A, 304) | Approx. 0.7 |
| Aluminum (Al) | Approx. 0.4 | Copper (Cu) | Approx. 0.3 |
| Brass (Br) | Approx. 0.4 | Remark | Associated graphic see "Installation" |
| A | 0 mm | B | 20 mm |
| C | 20 mm | D | 21 mm |
| E | 0 mm | F | 60 mm |
Specifications may be subject to change without notice
