WLG12-P537
Product ID:54118
Updated: 2026/7/7
Key Features
- 1Set sensitivity via a potentiometer for precise object detection.
- 2Detects objects in 0.6 ms, ideal for fast-moving and transparent objects.
- 3Detects reflective surfaces and thin films like stretch wrap.
- 4Offers 2 x PNP outputs for closed-loop process feedback and inspection.
- 5Measures 62 x 106 x 46.6 mm with an IP67 protection rating for harsh environments.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Sensor principle | Photoelectric retro-reflective sensor | Minimum detectable object (MDO) | Parallel beam, 6 mm ... 12.5 mm |
| Beam separation | 12.5 mm | Number of beams | 8 |
| Detection height | 87.5 mm | Resolution (adjustable) | 6 mm ... 12.5 mm |
| Wave length | 650 nm | Supply voltage Vs | DC 18 V ... 30 V |
| Power consumption sender | 80 mA | Ripple | < 5 V |
| Output current Imax. | ≤ 100 mA | Output load, capacitive | 100 nF |
| Output load, Inductive | 1 H | Initialization time | 0.6 s |
| Switching output | 2 x PNP | Output mode | Q dark switching |
| Teach-in input | PNP | Dimensions (W x H x D) | 62 mm x 106 mm x 46.6 mm |
| Connection type | Male connector M12, 5-pin | Housing material | Plastic |
| Indication | LED | Enclosure rating | IP67 |
| Circuit protection | UVconnections, reverse polarity protected#!#Output Q short-circuit protected#!#Interference pulse suppression | Protection class | II |
| Weight | 230 g | Front screen | PMMA |
| Maximum range | 1.5 m | Minimum range | ≥ 100 mm |
| Operating range | 1.5 m | Response time | Parallel beam, 0.6 ms |
Specifications may be subject to change without notice
