WTB12-3P2433T01
Product ID:59160
Updated: 2026/7/7
Key Features
- 1Detects objects with high accuracy even in complex backgrounds.
- 2Operates with a sensing range of 20 mm to 350 mm for versatile applications.
- 3Constructed with PTFE coating for resistance to harsh environments and easy cleaning.
- 4Switches in ≤ 330µs for real-time detection and control.
- 5Ensures reliable operation in various industrial conditions.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Functional principle | Photoelectric proximity sensor | Functional principle detail | Background suppression |
| Sensing range max. | 20 mm ... 350 mm | Sensing range | 20 mm ... 350 mm |
| Emitted beam_Light source | LED2) | Emitted beam_Type of light | Visible red light |
| Emitted beam_Light spot size (distance) | Ø 6 mm (200 mm) | Key LED figures_Wave length | 640 nm |
| Adjustment | Double teach-in button | Special applications | Hygienic and washdown zones |
| Supply voltage UB | 10 V DC ... 30 V DC | Ripple | < 5 V |
| Current consumption | 45 mA | Protection class | III |
| Digital output_Type | PNP | Digital output_Switching mode | Light/dark switching |
| Digital output_Output current Imax. | ≤ 100 mA | Digital output_Response time | ≤ 330 µs4) |
| Digital output_Switching frequency | 1,500 Hz5) | Output function | Complementary |
| Circuit protection | A6)#!#C7)#!#D8) | Housing | Rectangular |
| Dimensions (W x H x D) | 15.6 mm x 48.5 mm x 42 mm | Connection | Male connector M12, 4-pin |
| Material_Housing | PTFE coating | Weight | 120 g |
Specifications may be subject to change without notice
