3LD2766-1GP53
Product ID:102789
Updated: 2026/7/2
Key Features
- 1Quickly disconnect power in emergencies with reliable switching-off capability.
- 2Handle high-power applications using the robust 3-pole design.
- 3Support currents up to 100 A for demanding electrical circuits.
- 4Operate at up to 37 kW (400V AC-23A) for powerful industrial loads.
- 5Ensure durability with molded plastic encapsulation resistant to environmental conditions.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| AC Rated Voltage(V): | 690 | Insulation Voltage(V): | 690 |
| Description | Isolator Switch, Main Control and Emergency Stop Switch, 3LD2, 100A, 3P, Metric Thread Sealed Connector, Red/Yellow Handle, Plastic Housing Installation, AC-23A/37KW, 1NO+1NC | Installation Type: | Plastic Housing Installation |
| Terminal Type: | N | Others: | AC-23A/37KW, 1NO+1NC |
| Poles: | 3P | In(A): | 100 |
| Specification: | 3LD27【100A】 | Switch Type: | Metric Thread Sealed Connector, Red/Yellow Handle |
| Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
| ECCN | N | AL | N |
| Model Number | 3LD2766-1GP53 |
Specifications may be subject to change without notice
