Key Features
- 1Provide robust 710A protection against short circuits.
- 2Ensure secure connections with slotted blade contacts.
- 3Operate reliably with a high 690V AC voltage rating.
- 4Enhance safety using the gR non-cancelable operating class.
- 5Minimize energy consumption with low 72W power loss.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Description | SITOR Fuse Size 3 gR 710A 690VAC with Bolt-On Links | Rated Voltage | 690VAC |
| Type | gR [Semiconductor Full-Range Protection (Overload & Short Circuit Protection)] | Rated Current In (A) | 710 |
| Specifications | Size: 3 [560-850A] | Lifecycle | Delivery Release (PM300) |
| Country of Origin | Germany | ECCN | N |
| AL | N | Model Number | 3NE1437-3 |
Specifications may be subject to change without notice
