3NP1133-1JB20
Product ID:192061
Updated: 2026/7/3
Key Features
- 1Deliver high current capacity up to 160 A for demanding applications.
- 2Integrate seamlessly with Rittal busbar systems using a 40 mm width.
- 3Utilize a versatile 3-pole configuration for various electrical setups.
- 4Ensure enhanced safety with the reliable NH00 fuse switch disconnector type.
- 5Simplify installation via a compact design featuring a 32/70 mm cover level.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| DC Insulation Voltage(V): | 440 | AC Rated Voltage(V): | 690 |
| Insulation Voltage(V): | 1000 | Number of Poles: | 3P |
| Description | 3NP1, rated current 160A, Size 00/000, 40mm busbar system, box terminal, 3P, suitable for Rittal systems with base | Others: | Suitable for Rittal systems with base |
| Installation Type: | 40mm busbar system | Fuse Rating: | Size: 00/000 |
| Terminal Type: | Box Terminal | Rated Current In(A): | 160 |
| Specifications: | 3NP11【160A】 | Lifecycle | Delivery Release (PM300) |
| Country of Origin | Germany | ECCN | 9N9999 |
| AL | N | Model Number | 3NP1133-1JB20 |
Specifications may be subject to change without notice
