Key Features
- 1Deliver high-performance AC-3 operation rated for 9A at 400V.
- 2Integrate a varistor for enhanced surge protection in railway applications.
- 3Utilize an electronic drive for low switch-on and holding power consumption.
- 4Feature main contacts with 2 NO + 2 NC configuration and screw terminals.
- 5Mount easily with compact S00 size and versatile options.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Main Contact Configuration | 2NO+2NC | Wiring Method | Screw Terminal |
| Auxiliary Contacts | None | Coil Frequency | DC |
| Coil Power Supply | DC | Number of Poles | 4P |
| Rated Current AC-3 | 9A | Specification | S00 |
| Product Type | Four-pole Contactor | Lifecycle | Delivery Release (PM300) |
| Country of Origin | Germany | ECCN | N |
| AL | N | Model Number | 3RT2516-1XF40-0LA2 |
Specifications may be subject to change without notice
