Key Features
- 1Withstand harsh railway conditions like temperature fluctuations and EMI. 2、Install easily with screw or snap-on DIN rail mounting. 3、Operate flexibly within 0.7 to 1.25 times rated voltage (Us). 4、Protect against voltage spikes with an integrated varistor circuit. 5、Integrate seamlessly via IO-Link with modern control systems.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Main Contact Contact Configuration | 2NO+2NC | Wiring Method | Spring Terminal |
| Auxiliary Contacts | None | Coil Frequency | DC |
| Coil Power Supply | DC | Number of Poles | 4P |
| Rated Current AC-3 | 16A | Specification | S00 |
| Product Type | Quadruple Pole Contactor | Lifecycle | Delivery Release (PM300) |
| Country of Origin | Germany | ECCN | N |
| AL | N | Model Number | 3RT2518-2XF40-0LA2 |
Specifications may be subject to change without notice
