Key Features
- 1Handle high-power loads up to 22 kW at 400V for demanding applications. 2、Achieve 10 million mechanical cycles for exceptional long-term durability. 3、Mount easily via screw or snap-on options onto standard 35mm rails. 4、Ensure operational safety with IP00 protection on terminals and front. 5、Meet global compliance with IEC 60947-1 and other key standards.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Main Contact Configuration | 3NO | Wiring Method | Screw Terminal |
| Auxiliary Contacts | None | Coil Frequency | DC |
| Coil Power Supply | DC | Number of Poles | 3P |
| Rated Current AC-3 | 50A | Specification | S2 |
| Product Type | Contactor | Lifecycle | Delivery Release (PM300) |
| Country of Origin | China | ECCN | N |
| AL | N | Model | 3RT5036-1BM40 |
Specifications may be subject to change without notice
