Key Features
- 1Handle high power up to 7.5 kW at 400 V. 2、Ensure reliable operation with 1 NC 3-pole auxiliary contact. 3、Utilize a robust design for demanding industrial environments. 4、Achieve versatile compatibility with 50/60 Hz AC3 ratings. 5、Meet environmental safety with RoHS compliance since 2012.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Main Contacts Configuration | 3NO | Mechanical Life | 30 million operations (without auxiliary contacts on the main body) |
| Operating Temperature Range | -25~+60℃ | Auxiliary Contact | 1NC |
| Coil Voltage | 120V AC 50/60Hz | Coil Power Supply | 50/60Hz |
| Coil Frequency | AC | Number of Poles | 3P |
| Specification | S00 | Rated Current AC-3 | 16A |
| Product Type | Contactor | Lifecycle | Delivery Release (PM300) |
| Country of Origin | China | ECCN | N |
| AL | N | Model | 3RT6018-1AK22 |
Specifications may be subject to change without notice
