Key Features
- 1Handle up to 5.5 kW at 400 V for robust motor control. 2、Ensure reliable signaling with 1 NO + 1 NC auxiliary contacts. 3、Simplify installation via standard 35mm DIN-rail mounting. 4、Meet environmental standards with RoHS and WEEE compliance. 5、Reduce maintenance needs through a durable contact system.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Main Contact Configuration | 3NO | Wiring Method | Screw Terminal |
| Auxiliary Contacts | 1NO1NC | Coil Frequency | 50/60HZ |
| Coil Power Supply | AC | Number of Poles | 3P |
| Rated Current AC-3 | 12A | Specification | S0 |
| Product Type | Contactor | Lifecycle | Delivery Release (PM300) |
| Country of Origin | China | ECCN | N |
| AL | N | Model | 3RT6024-1AP20 |
Specifications may be subject to change without notice
