Key Features
- 1Control motors reliably with a robust AC-3 rating of 40A/18.5kW. 2、Ensure versatile application with 220-690V voltage compatibility. 3、Achieve 10 million mechanical switching cycles for extended service life. 4、Protect your system with 6kV surge voltage and shock resistance. 5、Simplify installation using screw terminals and compact S2 size.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Frame Code | S2 Specification | Main Contact Configuration | 3NO |
| Number of Poles | 3-pole | Rated Current (A) | AC-3 40A |
| Lifecycle | Delivery Release (PM300) | Country of Origin | China |
| ECCN | N | AL | N |
| Model Number | 3RT7035-1AN20 |
Specifications may be subject to change without notice
