Key Features
- 1Get a complete 22mm plastic-metal round illuminated pushbutton unit. 2、Operate momentarily with a flat button and secure holder. 3、Enhance visibility using the integrated green LED. 4、Connect easily to 110V AC/DC via screw terminals. 5、Ensure reliable switching with 1 green NO contact.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Operating Temperature Range | -25~+70℃ | Contact Rated Operating Current | 10A (AC-12 230V), 6A (AC-15 230V) |
| Rated Insulation Voltage | 600V | Others | None |
| Wiring Method | Screw Terminal | Operating Voltage | 110V AC |
| Illumination Type | LED | Accessory Contacts | 1NO |
| Diameter | Hole Diameter 22mm | Color | Green |
| Enclosure Material | Metallic | Operation Mode | Momentary |
| Button Type | Illuminated Flat Head Button | Type | Complete Button Set |
| Product Type | Illuminated Flat Head Button | Lifecycle | Delivery Release (PM300) |
| Country of Origin | China | ECCN | N |
| AL | N | Model Number | 3SB6135-0DB40-1BA0 |
Specifications may be subject to change without notice
