3US5040-0G
Product ID:100468
Updated: 2026/4/3
Key Features
- 1Ensure precise motor protection with tripping class 10A for reliable overload response. 2、Operate within a versatile 0.4...0.63 A current range for various applications. 3、Simplify control logic using 1 NO + 1 NC integrated auxiliary contacts. 4、Save panel space with a compact design that reduces wiring costs. 5、Access comprehensive support including manuals and certificates for easy setup.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Operating Ambient Temperature | -40~+70°C | Operating Altitude | 2000m |
| Rated Voltage | AC400V | Matching Contactor | S0 [3TS29/30/31/32] |
| Mounting Method | Plug-in mounting with contactor | Specification | S0 |
| Load Class | CLASS 10 | Current Setting Range | 0.4-0.63A |
| Rated Current (AC-3) | Max 18A for S0 size | Series | 3US5/6 Series |
| Lifecycle | Delivery Release (PM300) | Country of Origin | China |
| ECCN | N | AL | N |
| Model | 3US5040-0G |
Specifications may be subject to change without notice
