3VA1150-5GF42-0AA0
Product ID:99133
Updated: 2026/4/3
Key Features
- 1Achieve high breaking capacity up to 55 kA at 415 V. 2、Ensure selective protection for enhanced safety and reliability. 3、Integrate overload protection with In=50 A and Ir=35 A. 4、Utilize compact design with plug-in and draw-out technology. 5、Access a wide range of modular accessories for flexible use.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Rated Service Breaking Capacity Ics(kA): @400V or 415V | 55 | Rated Voltage(V): | 690 |
| Number of Poles: | 4P | Description | 3VA1M160 R50 TM240N F/4P; 3VA1_160 dimensions; Rated current 50A; Interrupting rating M: 55 kA; Trip unit TM240N; |
| Mounting Method: | F: Fixed | Trip Unit: (If required is not in the list, click reset, select trip unit first) | TM240N [Thermal Magnetic Type LI] |
| Rated Ultimate Breaking Capacity Icu(kA): @400V or 415V | 55 | Interrupting Rating: | M: 55 kA |
| Rated Current In(A): | 50 | Specifications: | 160 [1-160A] |
| Lifecycle | Delivery Release (PM300) | Country of Origin | China |
| ECCN | N | AL | N |
| Model Number | 3VA1150-5GF42-0AA0 |
Specifications may be subject to change without notice
