3VA2563-7HN32-0AA0
Product ID:219767
Updated: 2026/4/5
Key Features
- 1Deliver reliable line protection with a 35 kA breaking capacity. 2、Utilize the advanced ETU350 electronic trip unit for precision. 3、Adjust overload protection from 250A to 630A for safety. 4、Ensure system integrity with a 110kA interrupting rating. 5、Configure for 3-pole applications with screw flattop connectors.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Ics(kA)@690V: | 19 | Icu(kA)@690V: | 35 |
| Rated Service Intermittent Breaking Capacity Ics(kA): @400V or 415V | 110 | Rated Voltage(V): | 415 |
| Number of Poles: | 3P | Description | 3VA2C1000 R630 ETU350 F/3P; 3VA2_1000 dimensions; Rated Current 630A; Interrupting Rating C:110kA; Trip Unit ETU350 |
| Mounting Method: | F: Fixed | Trip Unit: (If required is not in the list, click reset, select trip unit first) | ETU350 [Electronic LSI] |
| Rated Ultimate Breaking Capacity Icu(kA): @400V or 415V | 110 | Interrupting Rating: | C:110kA |
| Rated Current In(A): | 630 | Specifications: | 1000 [630-1000A] |
| Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
| ECCN | 9N9999 | AL | N |
| Model Number | 3VA2563-7HN32-0AA0 |
Specifications may be subject to change without notice
