5SJ4102-8HG41
Product ID:102983
Updated: 2026/7/2
Key Features
- 1Provide reliable protection with a high 14kA interrupt rating.
- 2Save panel space using a compact, DIN-rail mount design.
- 3Simplify field wiring with compatibility for 14-4 AWG copper.
- 4Ensure operator safety with an IP20-rated, touch-protected enclosure.
- 5Accelerate installation via straightforward DIN rail mounting.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Installation Module | 1 | Description | 5SJ4 1P D2, 240V AC 10KA; Rated Current 2A; Breaking Capacity 10kA; Trip Unit D |
| Others | 240VAC | Breaking Capacity Icn(kA) Standard IEC60898 | 10 |
| Number of Poles | 1P | Trip Unit | D【D characteristic curve】 |
| Rated Current In(A) | 2 | Specifications | 5SJ4-HG【0.6-63A】 |
| Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
| ECCN | N | AL | N |
| Model Number | 5SJ4102-8HG41 |
Specifications may be subject to change without notice
