5SJ4135-8HG40
Product ID:102403
Updated: 2026/4/3
Key Features
- 1Meet stringent safety standards with UL and CSA certifications. 2、Ensure robust protection with high 14kA interrupting ratings. 3、Provide reliable overcurrent protection via thermal-magnetic tripping. 4、Simplify installation using standard DIN rail mounting. 5、Select versatile current ratings from 0.3 to 63 Amps.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Mounting Unit | 1 | Description | 5SJ4 1P D35 same polarity only, 240V AC; Rated Current 35A; Breaking Capacity 10kA; Trip Unit D |
| Breaking Capacity Icn(kA) Standard IEC60898 | 10 | Number of Poles | 1P |
| Trip Unit | D【D Characteristic Curve】 | Rated Current In(A) | 35 |
| Specifications | 5SJ4-HG【0.6-63A】 | Lifecycle | Delivery Release (PM300) |
| Country of Origin | Germany | ECCN | N |
| AL | N | Model Number | 5SJ4135-8HG40 |
Specifications may be subject to change without notice
