5SN3006-7CN
Product ID:206804
Updated: 2026/4/3
Key Features
- 1Deliver high torque output of 30Nm for efficient operation. 2、Utilize a compact design with recessed flange for space-saving. 3、Monitor temperature precisely with an integrated Pt1000 sensor. 4、Ensure accurate positioning via an EnDat 2048 S/R absolute encoder. 5、Enable custom applications with a specially geared shaft.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Installation Module | 1 | Specification | 5SN3【6-40A】 |
| Number of Poles | 1P+N | Trip Unit | C【C characteristic curve】 |
| Breaking Capacity Icn(kA) per IEC60898 Standard | 4.5 | Rated Current In(A) | 6 |
| Lifecycle | Delivery Release (PM300) | Country of Origin | China |
| ECCN | N | AL | N |
| Model Number | 5SN3006-7CN |
Specifications may be subject to change without notice
