5SU1654-7KK10
Product ID:99802
Updated: 2026/4/3
Key Features
- 1Withstand high surge currents exceeding 3 kA for robust protection. 2、Enable selective shutdown to enhance safety and system efficiency. 3、Ensure compliance with the RoHS directive for environmental safety. 4、Integrate easily into distribution boards with a compact design. 5、Provide safe touch protection for fingers and back of hand.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Description | 5SU1_A_0.3 1P+N C10 10KA; Rated Current 10A; Breaking Capacity 10kA; Trip Unit C; 1P+N; Residual Current 300mA; Type A; Electromagnetic | Testing Method: (ELE: Electronic, ELM: Electromagnetic) | Electromagnetic |
| Leakage Current Type: | A | Residual Current: | 300 mA |
| Breaking Capacity Icn(kA): Standard IEC60898 | 10 | Product Type: | Residual Current Protective Circuit Breaker |
| Trip Unit: | C【C characteristic curve】 | Number of Poles: | 1P+N |
| In(A): | 10 | Lifecycle | Delivery Release (PM300) |
| Country of Origin | Germany | ECCN | N |
| AL | N | Model Number | 5SU1654-7KK10 |
Specifications may be subject to change without notice
