5SU9356-8CN16
Product ID:152939
Updated: 2026/4/3
Key Features
- 1Ensure reliable 1+N 6kA CN D-Char A-type circuit protection. 2、Deliver precise 16A power management for critical applications. 3、Guarantee long-term performance with PM300 product lifecycle. 4、Support global e-commerce and industrial electrical system needs. 5、Provide certified operation across diverse electrical environments.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Description | 5SU9/SN 30mA 1P+N 6kA D16; Rated Current 16A; Breaking Capacity 6kA; Trip Unit D; 1P+N; Residual Current 30mA; A; Electronic | Inspection Method: (ELE: Electronic, ELM: Electromagnetic) | Electronic |
| Leakage Current Type: | A | Residual Current: | 30mA |
| Breaking Capacity Icn(kA): Standard IEC60898 | 6 | Product Type: | Residual Current Protective Circuit Breaker |
| Trip Unit: | D【D Characteristic Curve】 | Number of Poles: | 1P+N |
| In(A): | 16 | Lifecycle | Delivery Release (PM300) |
| Country of Origin | China | ECCN | N |
| AL | N | Model Number | 5SU9356-8CN16 |
Specifications may be subject to change without notice
