5SV9316-7CN32
Product ID:224421
Updated: 2026/8/26
Key Features
- 1Provide instantaneous protection against short circuits.
- 2Handle high 6 kA short-circuit breaking capacity reliably.
- 3Fit into space-constrained panels with a compact design.
- 4Enhance safety using a versatile 1P+N configuration.
- 5Ensure reliable continuous operation at 240 V AC.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Product Type | Residual Current Protective Circuit Breaker | Number of Poles | 1P+N |
| Description | 5SV9/SN A 30mA 1P+N 6KA C32; Rated Current 32A; Breaking Capacity 6kA; Trip Unit C; 1P+N; Residual Current 30mA; A; Electronic | Testing Method (ELE Electronic, ELM Electromagnetic) | Electronic |
| Leakage Current Type | A | Residual Current | 30 mA |
| Trip Unit | C [C Characteristic Curve] | Breaking Capacity Icn(kA) per IEC60898 Standard | 6 |
| Rated Current In(A) | 32 | Lifecycle | Delivery Release (PM300) |
| Country of Origin | China | ECCN | 9N9999 |
| AL | N | Model Number | 5SV9316-7CN32 |
Specifications may be subject to change without notice
