7ML5630-0AA00-0JA0
Product ID:221347
Updated: 2026/4/3
Key Features
- 1Detect level and interface in liquids, solids, slurries, and foam. 2、Adjust insertion up to 5.5 m for versatile application. 3、Tune sensitivity to ignore build-up on the probe. 4、Utilize durable 316L stainless steel probe body. 5、Ensure safety with CSA/FM Class II, III Div.1 approvals.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Electrical Interface and Protection Rating | 2*1/2"NPT, IP65 | Explosion Protection Type | Non-explosive-proof |
| Probe Material | 19mm 316L hard rod with PPS coating | Wetted Seal Material | FKM |
| Thermal Isolation | Standard | Measuring Rod Length | 120mm |
| Process Connection and Material | 3/4"NPT, 316L stainless steel | Product Series | SITRANS CLS200 |
| Lifecycle | Delivery Release (PM300) | Country of Origin | Germany |
| ECCN | EAR99 | AL | N |
| Model Number | 7ML5630-0AA00-0JA0 |
Specifications may be subject to change without notice
