BPZ:MXF461.15-0.6
Product ID:160881
Updated: 2026/4/4
Key Features
- 1Adjust room temperature with high accuracy using the setpoint adjustment knob. 2、Ensure safe operation in cold conditions with frost protection position. 3、Provide reliable control with setpoint locking and limit stops. 4、Mount directly on Siemens radiator valves and compatible third-party valves. 5、Enhance energy efficiency and reduce costs with Smart Infrastructure 7.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Leakage Rate | 0.02% of kvs | Bypass Leakage Rate | 0.2% of kvs |
| Operating Range | DC 0…10 V | Operating Voltage | AC 24 V; DC 24 V |
| Positioning Time | DC 0...10 V; DC 2...10 V; DC 4...20 mA | Positioning Signal | DC 0...10 V; DC 2...10 V; DC 4...20 mA |
| Installation Position | Vertical to the horizontal plane | Power Consumption | 29 VA |
| Permissible Operating Pressure | 1000 kPa | Lifecycle | P.M300 |
| Country of Origin | Switzerland | ECCN | N |
| AL | N | Model | BPZ:MXF461.15-0.6 |
Specifications may be subject to change without notice
