BPZ:MXG461B40-20
Product ID:149339
Updated: 2026/7/2
Key Features
- 1Achieve precise modulating control for accurate fluid mixing.
- 2Ensure industrial compatibility with external thread, PN16, and DN40.
- 3Utilize versatile 24V AC or DC control signals for flexibility.
- 4Support high flow rates with a kvs value of 20.
- 5Rely on magnetic actuator and spring return for long service life.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Leakage Rate | 0.05% of kvs | By-pass Leakage Rate | 0.2% of kvs |
| Operating Range | DC 0…10 V; 0…20 mA; DC 2…10 V; 4…20 mA | Operating Voltage | AC 24 V; DC 20…30 V |
| Positioning Time | DC 0...10 V; DC 2...10 V; DC 4...20 mA; DC 0...20 mA; DC 0...20 V Phs | Positioning Signal | DC 0...10 V; DC 2...10 V; DC 4...20 mA; DC 0...20 mA; DC 0...20 V Phs |
| Installation Position | Vertical to the horizontal plane | Power Consumption | 43 VA |
| Permissible Operating Pressure | 1600 kPa | Lifecycle | P.M300 |
| Country of Origin | Switzerland | ECCN | N |
| AL | N | Model Number | BPZ:MXG461B40-20 |
Specifications may be subject to change without notice
