Key Features
- 1Measure temperature with high precision of ±1 K from 0 to 70 °C.
- 2Ensure reliable performance across a wide -10 to 120 °C measuring range.
- 3Output stable 4…20 mA signals with a 13.5…35 V DC operating voltage.
- 4Install easily using the G ½" thread and robust IP54-rated housing.
- 5Secure durable connections with the stainless steel pocket and screw terminals.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Dimensions (Width x Height x Length) | 80 x 88 x 39 mm | Connection Method | Threaded Connection |
| Installation Method | Protection Sleeve G½" | Measurement Accuracy | At 0…70 °C: ±1 K |
| Operating Voltage | DC 13.5...35 V | Lifecycle | P.M300 |
| Country of Origin | China | ECCN | 9N9999 |
| AL | N | Model | BPZ:QAE2174.010 |
Specifications may be subject to change without notice
