S55264-V128
Product ID:172152
Updated: 2026/4/3
Key Features
- 1Support high flow rates from 550 to 4000 l/h. 2、Integrate pressure test points for precise control and monitoring. 3、Meet industry standards with PN25 and DN32 specifications. 4、Serve versatile ventilation, heating, and cooling applications. 5、Utilize a pre-adjustable combi valve design for efficient hydraulic balancing.
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Leakage Rate | Class IV (0…0.01% of volume flow V<sub>100</sub>) | Installation Position | Vertical to 90° inclination |
| Working Pressure | 2500 kPa | Lifecycle | P.M300 |
| Country of Origin | Switzerland | ECCN | N |
| AL | N | Model Number | S55264-V128 |
Specifications may be subject to change without notice
