2052-391
Product ID:48029
Updated: 2026/7/15
Key Features
- 1Compact design for small spaces.
- 2Multiple mounting options: DIN 15 rail, panel fixing, snap-in foot.
- 3High current capacity: 24 A (32 A) at 500 V IEC / 300 V UL.
- 4Fast identification with printable marker strips.
- 5Compatible with existing WAGO accessories.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width | 3.4?mm?/ 0.134?inches | Height | 34.5?mm?/ 1.358?inches |
| Depth | 28.7?mm?/ 1.13?inches | Mounting type | snap-on type |
| Note (material data) | Information on material specifications can be found here | Color | gray |
| Material group | I | Insulation material (main housing) | Polyamide (PA66) |
| Flammability class per UL94 | V0 | Fire load | 0.039MJ |
| Weight | 1.3g | ETIM 9.0 | EC000886 |
| ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 100?(25)?pcs | Packaging type | Box |
| Country of origin | DE | GTIN | 4066966154702 |
| Customs tariff number | 85389099990 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
