280-346
Product ID:44632
Updated: 2026/7/19
Key Features
- 12 mm thick, oversized separator plate for enhanced durability.
- 2Designed for easy integration into electrical systems with a gray color.
- 3Orange-colored, suitable for harsh environments with a width of 2 mm.
- 4Compatible with WAGO's 280 series modular components.
- 5Meets ROHS standards, ensuring environmental safety and compliance.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width | 2?mm?/ 0.079?inches | Height | 63.8?mm?/ 2.512?inches |
| Depth | 26.5?mm?/ 1.043?inches | Note (material data) | Information on material specifications can be found here |
| Color | orange | Material group | I |
| Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
| Fire load | 0.076MJ | Weight | 2.5g |
| Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
| Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
| eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
| ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 100?(25)?pcs | Packaging type | box |
| Country of origin | DE | GTIN | 4017332150521 |
| Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
