282-137
Product ID:49953
Updated: 2026/7/13
Key Features
- 1High-Current Capacity: Withstands up to 22,200 A for 1 second, ensuring robust performance in demanding electrical systems.
- 2Durable CAGE CLAMP Connection: Proven to withstand extreme current tests without damage or reduced functionality.
- 3Versatile Conductor Range: Suitable for conductors from 0.14 to 1.5 mm², accommodating various electrical needs.
- 4Compact Design: Ideal for rail-mounted applications with a terminal block width of 3.5 mm, enhancing space efficiency.
- 5Reliable Voltage Drop: Maintains voltage drop within 10 mV, ensuring consistent electrical performance.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Note (material data) | Information on material specifications can be found here | Color | orange |
| Material group | I | Insulation material (main housing) | Polyamide (PA66) |
| Flammability class per UL94 | V0 | Fire load | 0.022MJ |
| Weight | 0.7g | Processing temperature | -35 … +85?°C |
| Continuous operating temperature | -60 … +105?°C | Product Group | 1 (Rail Mounted Terminal Blocks) |
| eCl@ss 10.0 | 27-14-11-92 | eCl@ss 9.0 | 27-14-11-92 |
| ETIM 9.0 | EC002848 | ETIM 8.0 | EC002848 |
| ECCN | NO US CLASSIFICATION | PU (SPU) | 100?(25)?pcs |
| Packaging type | box | Country of origin | DE |
| GTIN | 4017332286022 | Customs tariff number | 3926909985 |
| RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
