283-352
Product ID:47508
Updated: 2026/7/15
Key Features
- 1Withstands 22,200 A of short-time current, ensuring reliable connections in demanding applications.
- 2Automatic clamping mechanism that securely connects wires without damage, eliminating the need for wire preparation.
- 3Designed to pass the "120 A per mm²" test for 3x one second without damage or reduced functionality.
- 4Suitable for various conductor sizes from 0.08 mm² to 35 mm², making it adaptable to different wiring needs.
- 5Meets industry standards with approvals for Ex i and Ex e II applications, ensuring safe operation in hazardous environments.
Need a quote? Enter your quantity and get pricing fast.
Qty
Technical Specifications
Detailed engineering parameters
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Width | 2.5?mm?/ 0.098?inches | Height | 104.3?mm?/ 4.106?inches |
| Depth | 37.5?mm?/ 1.476?inches | Note (material data) | Information on material specifications can be found here |
| Color | orange | Material group | I |
| Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
| Fire load | 0.204MJ | Weight | 7.2g |
| Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
| Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
| eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
| ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
| PU (SPU) | 50?(25)?pcs | Packaging type | box |
| Country of origin | DE | GTIN | 4017332291781 |
| Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
